Tri-Clean by BrandMax Ultrasonic Cleaners

Tri-Clean ultrasonic cleaners by BrandMax provide superior cleaning power which results in cleaner instruments. All Tri-Clean ultrasonic units come standard with heating element,cycle time controller and stainless steel basket,there is no need to pay extra for these valuable options when BrandMax provides them for free!

Take the Tri-Clean Challenge . . .

FEATURE Tri-Clean Competitor BENEFIT
All stainless steel construction Scratch resistant, durable and easy to clean
Stainless steel drain valve Easy and effective draining of soiled cleaning solution
Digital timer Control time for worry free cleaning cycles
Superior acoustic pulse generators Powerful cavitations loosen bio-burden from instruments
Heating element included Expensive option included for free!
Stainless steel basket included Expensive option included for free!
Works with all popular cassette systems Supports instrument management
1 year warranty on unit & electronics /
2 year warranty on transducers		 Comprehensive protection for your investment
Superior customer service “Best in Class” product support
Model #
Cleaning
Tank Capacity Gallons/Liters
Temp Range
Timer Setting
Power Sonic/Heat
Tank
Dimensions
L x W x H (in.)
Basket
Dimensions
L x W x H (in.)
Overall
Dimensions
L x W x H(in.)
Unit Weight
(lbs.)
Shipping Weight
(lbs.)
Shipping
Dimensions
L x W x H(in.)
COUNTER-TOP MODELS – SPECIFICATION CHANGES FROM PREVIOUS CATALOGS APPLY TO SN 3260 AND HIGHER
U-5LH 1.05 gal / 4L 68-120 °F
20-60 °C		 1 – 99
min		 120W / 200W 9.5 x 5.5
X6 in.		 8.25 x 4.25
x 4.25 in.		 11 x 7
x 10.75 in.		 11 lbs. 13 lbs. 15 X 10
X 13 in.
U-10LH 2.64 gal / 10L 68-120 °F
20-60 °C		 1 – 99
min.		 220W / 350W 12 x 9.5
x 6 in.		 10.5 x 8.25
x 4.25 in.		 13.5 x 11
x 11.5 in.		 17 lbs. 22 lbs. 18 X 15
X 15 in.
U-13LH 3.43 gal / 13L 68-120 °F
20-60 °C		 1 – 99
min.		 300W / 450W 13 x 11.8
x 6 in.		 11.6 x 10.6
x 4.25 in.		 14.75 x 13.75
x 13 in.		 25 lbs. 32 lbs. 20 x 17
X 15 in.
U-19LH 4.94 gal / 19L 68-120 °F
20-60 °C		 1 – 99
min.		 300W / 450W 13 x 11.8
x 8 in.		 11.6 x 10.6
x 6.25 in.		 14.75 x 13.75
x 15 in.		 29 lbs. 36 lbs. 20 x 17
X 17 in.
U-20LH 5.06 gal / 20L 68-120 °F
20-60 °C		 1 – 99
min.		 430W / 650W 20 x 12
x 6 in.		 18.85 x 11.25
x 4.25 in.*		 21.75 x 13.75
x 13 in.		 36 lbs. 42 lbs. 28 X 17
X 15 in.
U-40LH** 10.56 gal / 40L 68-120 °F
20-60 °C		 1 – 99
min.		 800W / 1240W 24.5 x 19.5
x 6 in.		 (2) 18.5 x 10.6
x 4.25 in.		 25.5 x 21
x 16.75 in.		 53 lbs. 73.5 lbs. 29 X 23
X 22 in.

For counter top units, please add 2” to length dimension for external drain spout. | 220V option available as special order.
*U-40LH is special order only , and does not have heat.

Be sure to check out our Ultrasonic Cleaner product video at: www.BrandMax.us/News-Marketing

Tri-Clean by BrandMax Recessed Ultrasonic Cleaners

Tri-Clean recessed ultrasonic cleaning units offer an attractive alternative to above counter models. Our all stainless steel recessed units offers the same premium features and benefits as our above counter models but also an extended control cord for above or below counter mounting of control panel.

Model #
Cleaning
Tank Capacity Gallons/Liters
Temp Range
Timer Setting
Power Sonic/Heat
Tank
Dimensions
L x W x H (in.)
Basket
Dimensions
L x W x H (in.)
Overall
Dimensions
L x W x H(in.)
Minimum
Counter
Opening
W x D(in.)
Unit Weight
(lbs.)
Shipping Weight
(lbs.)
Shipping
Dimensions
L x W x H(in.)
RECESSED MODELS – SPECIFICATION CHANGES FROM PREVIOUS CATALOGS APPLY TO SN 3260 AND HIGHER
U-10LHREC 2.64 gal / 10L 68-120 °F
20-60 °C		 1 – 99
min.		 220W / 350W 12 x 9.5
x 6 in.		 10.5 x 8.25
x 4.25 in.		 18.6 x 16.2
X 11.5 in.		 15.5 x 11.5 in. 26 lbs. 34 lbs. 21 X 19
X 15 in.
U-13LHREC 3.43 gal / 13L 68-120 °F
20-60 °C		 1 – 99
min.		 300W / 450W 13 x 11.8
x 6 in.		 11.6 x 10.6
x 4.25 in.		 19.25 x 18.10
X 13 in.		 17 x 14 in. 33 lbs. 41 lbs. 23 x 21
X 15 in.
U-19LHREC 4.94 gal / 19L 68-120 °F
20-60 °C		 1 – 99
min.		 300W / 450W 13 x 11.8
x 8 in.		 11.6 x 10.6
x 6.25 in.		 19.25 x 18.10
x 15 in.		 17 x 14 in. 36 lbs. 44 lbs. 23 x 21
x 17 in.
U-20LHREC 5.06 gal / 20L 68-120 °F
20-60 °C		 1 – 99
min.		 430W / 650W 20 x 12
x 6 in.		 18.85 x 11.25
x 4.25 in.*		 26.75 x 18.6
X 13 in.		 24.5 x 15 in. 44 lbs. 53 lbs. 29 x 21
X 15 in.
Matching Soaking Tank for U-19LHREC
ST-19L 4.94 gal / 19L N/A N/A N/A 13 x 11.8
x 8 in.		 11.6 x 10.6
x 6.25 in.		 19.25 x 18.10
x 15 in.		 15.5 x 14 in. 25lbs 32lbs 23 x 21
x 17 in.

* New 20L basket size, SN 3498 and higher

How do you maximize your cleaning process..

Ultrasonic Cleaner Accessories

Half-Basket

HALF-BASKET BASKETS

Model # Order # Dimensions L x W x H (in.)
U-10LH/REC UHB-5L 8.2 x 4.2 x 4.3
U-13LH/REC 3GHB 11.8 x 5.3 x 4.3
U-19LH/REC 3GHB 11.8 x 5.3 x 4.3
U-20LH/REC UHB-10L 10.5 x 8.2 x 4.3

INSTRUMENT CASSETTE BASKETS (non-hanging)

  • UB-3L
 Stainless steel instrument cassette basket for 3L
  • UB-5L
 Stainless steel instrument cassette basket for 5L
  • UB-10L
 Stainless steel instrument cassette basket for 10L
  • UB-13L
 Stainless steel instrument cassette basket for 13L
  • UB-20L
 Stainless steel instrument cassette basket for 20L
Handled Baskets
Hanging Baskets

HANGING BASKETS

  • UHB-3L
 Stainless steel hanging basket for 3L
  • UHB-5L
 Stainless steel hanging basket for 5L
  • UHB-10L
 Stainless steel hanging basket for 10L
  • UHB-13L
 Stainless steel hanging basket for 13L
  • UHB-19L
 Stainless steel hanging basket for 19L
  • UHB-20L
 Stainless steel hanging basket for 20L
Beaker Holder

BEAKER HOLDER

Diameter of each beaker holder opening is 3.5”

  • BH1
 Stainless steel beaker holder, for U-5LH, U-10LH and U-10LHREC units
  • BH13
 Stainless steel beaker holder for U-13LH, U-13LHREC, U-19LH and U-19LHREC units
  • BH20
 Stainless steel beaker holder for U-20LH and U-20LHREC units

BURR BASKET

  • BB1
 Stainless steel burr basket,2” round with closing lid
Burr Basket

ULTRASONIC CLEANER PARTS

  • CB1
 Control Board, table-top units
  • CB2
 Control Board, recessed units
  • CK2
 Converts automatic drain to manual drain on BrandMax recessed units
  • FIL1
 For all U-3LH, U-5LH, U-5LHREC, U-10LH units. For 10LHREC and all 13L and 20L units SN 3259 and lower. Please specify Serial Number and model number when ordering.
  • FIL2
 For all 20L, 13L units and 10LHREC serial number 3260 and above. Please specify Serial Number and model number when ordering.
  • PB1
 Power Board (all units)
  • PS1
 Master Power Switch, table-top units
  • S10
 Solenoid Valve for all units. Please specify model number and serial number when ordering.
FIL2 Filter
Optional CK3 Controller

CONTROL PANELS

  • CK3
 Standard flush mount control panel for recessed units.
(11” wide x 6.25” tall)

ENZYME GALLON PUMP

  • GP-25
 Pump for gallon size, dispenses 1oz of solution per pump.

Ultrasonic Cleaner Video

null
We recommend BrandMax Triple Enzyme Cleaners
Download Product Catalog

Why is heat important?

Heat is a crucial element to maximize the enzymatic activity and heating your enzymatic solution can improve the overall cleaning effectiveness.
